Multi-Radius Tip-Type Punch
SK10,11
| Tool Number Name/Spec. |
Tool Profile | V Angle | Edge R | Cat.No. | Allow.Ton. | Edge Width | Weight (kg) |
Size |
|---|---|---|---|---|---|---|---|---|
| Tip-Type Small
Radius Holders R3-R5 One Touch (SK11) |
 |
---- | ---- | 091041 | ---- | ---- | 10.0 | L |
| 091042 | 5.0 | S | ||||||
| 091841 | 10.0 | Sect. | ||||||
| Tip-Type Large
Radius Holders R6-R10 One Touch (SK11) |
---- | ---- | 091061 | ---- | ---- | 10.0 | L | |
| 091062 | 5.0 | S | ||||||
| 091861 | 10.0 | Sect. | ||||||
| Tip-Type Multi-
Radius Holders (Straight Groove) (SK10) |
---- | ---- | 091001 | ---- | ---- | 10.0 | L | |
| 091002 | 5.0 | S | ||||||
| 091801 | 10.0 | Sect. | ||||||
| Tip-Type Small Radius Tip Only R3～R5(SK10) |
 |
R3 tip | 090301 | ---- | ---- | 0.2 | L | |
| 090302 | 0.1 | S | ||||||
| 090831 | 0.2 | Sect. | ||||||
| R4 tip | 090401 | ---- | ---- | 0.3 | L | |||
| 090402 | 0.15 | S | ||||||
| 090841 | 0.3 | Sect. | ||||||
| R5 tip | 090501 | ---- | ---- | 0.5 | L | |||
| 090502 | 0.25 | S | ||||||
| 090851 | 0.5 | Sect. | ||||||
| Tip-Type Large Radius Tip Only R6～R10(SK10) |
|
R6 tip | 090601 | ---- | ---- | 0.7 | L | |
| 090602 | 0.35 | S | ||||||
| 090861 | 0.7 | Sect. | ||||||
| R8 tip | 090801 | ---- | ---- | 1.3 | L | |||
| 090802 | 0.6 | S | ||||||
| 090881 | 1.3 | Sect. | ||||||
| R10 tip | 090101 | ---- | ---- | 2.1 | L | |||
| 090102 | 1.0 | S | ||||||
| 090811 | 2.1 | Sect. | ||||||
※Sectionalized Length (20,25,30,35,40,50,70,100(L),100(R),165,200 Total835mm)
※Small Radius Tip is for Small Radius Holder / Multi-Radius Holder. Large Radius Tip is for Large Radius Holder. / Multi-Radius Holder. e.g.) Small Radius Tip can not be mounted on Large Radius Holder.
