Fine Offset Tool

This FEL data is not for V-bending. ( Value "D" can not be calculated.) Therefore, please download the data after reading the following notice carefully.
>Use "Direct Data" mode.
("3D Data"/"Shape Data"/"Angle Data" are Not Available.)

*Direct Data: Input values "L" and "D" on "Run Display" or "Prog Display" through from "Bend Process Display/Tool Select Display"

Not possible to calculate D value (Except V bend type tool)
Radius Bend 3U Die Offset Tool Hemming Wing Bend
Radius Bend 3U Die Offset Tool Hemming ウイングベンド

Download

The following data is contained.

FELNo. Product Notes Image
362959 Fine Offset Tool
